10MPa Horizontal Directional Drill XZ1350F Peralatan HDD Untuk Pemasangan Pipa

Tempat Asal:Cina

Nama merek:Rongchang Machinery

Jumlah Pesanan Minimum:1 PC

Harga:Dapat dinegosiasikan

Ketentuan Pembayaran:L/C, T/T, dll.

Detail Produk

Menyoroti:

Pengeboran arah horizontal 10mpa

,

Peralatan xz1350f HDD

,

Pengeboran arah horizontal xz1350f

Deskripsi Produk

Peralatan HDD Precision Horizontal Directional Drill untuk Instalasi Saluran

proyek	unit	XZ1350F
mesin	-
daya nominal	kW/r/menit	264/2100
Kekuatan dorongan dan tarik balik maksimum	kN	1350
Kecepatan dorongan dan tarik balik maksimum	m/menit	45
Torsi	N·m	48000
Kecepatan maksimum	r/menit	100
Aliran maksimum	L/menit	800
tekanan terbesar	MPa	10
Pipa bor	mm × m	φ114/φ127×6
Berat angkat	t	2
Saat angkat	t·m	4
Sudut penetrasi maksimum	°	18
kualitas	t	25
Dimensi	mm	11680 × 2760 × 3550
Perhatikan	-	Opsional: Peningkatan daya
